Offering seven different predefined muting configuration options including bypass mute dependent override mute enable and mute cycle time extensions for l style cell exit application the safety light curtain provides versatile performance for diverse application requirements. When there is no access for persons but the access for products must be available a muting light curtain offers a perfect solution. Light curtain with muting two sensor l type and configurable safety relay introduction light curtains are used to detect attempted access to a hazardous area. Safety light curtains continental corporation a leading firm in the manufacturing of electronic car components has always made extensive use of these safety devices in its plants especially in areas where moving components could injure operators.

In normal operation if a light curtain detects an object it causes the safety system to stop any hazardous motion in the hazardous area. Identification of safety functions 2. Muting sensors shall be positioned beyond the light curtain in the dangerous area. With a muting light screen access to a hazardous area is temporarily disabled muting allowing products to enter the hazardous area.

Muting is defined as bypassing the protective function on safety related control system such as a safety light curtain during a pre determined operation of a machine. Muting shall be desabled as soon as the light curtain is cleared and not later than 4 seconds max. We have installed bypass keys on our press light curtains because someone realized that if an operator got caught in a die they would be standing in the light curtain. Gl r series safety light curtains offers a robust solution for optimal levels of safety.

10 ma with edm input only when using an npn output cable. The terms muting and blanking are frequently used incorrectly. 10 to 30 v off voltage. Open or 0 to 3 v short circuit current.

Setup of a muting light curtain. Open or 10 v or more up to the power voltage. A safety light curtain shields a hazardous area for people s access. Determination of required pl plr for each safety function.

There is no muting override in this example. Safety light curtains can be used in a variety of different modes such as muting blanking and floating blanking depending on the needs of the application. This post will help clarify the difference between the two so the correct safety light curtain functionality is chosen and the machine runs safely. Edm input wait input reset input muting input 1 2 override input.

Muting input 1 2 override input. Specification of characteristics of each function 3. 0 to 3 v off voltage. This application technique describes the operation of a light curtain with muting functionality.

Safety light curtains the xpslcmut1160 muting safety module is an acce ssory device used to provide a safety rated muting function in conjunction with safety light curtain.
