Mains Plug Fuse Rating

Plugs fitted with bs 546 fuses have been optional since the original bs 546 1934 with maximum fuse ratings of 2 a in the 2 a plug and 5 a in the 5 a 15 a and 30 a plugs.

Mains plug fuse rating.

So if you have a 240 volt heater rated at 3 kw 3000 watts it will have a load of 12 5 amps therefore it requires a fuse rated at 13 amps. In practice most bs 546 plugs are unfused with fused versions being unusual and expensive. For an appliance rated as 700w or less a 3a fuse should be fitted. Plugs for appliances rated between about 700 watts and 3000 watts the maximum rating of a wall socket should be fitted with a 13 amp fuse coloured brown.

13a fuse washing machine dishwasher microwave kettle toaster iron. The problem in most homes is that if a replacement plug top is fitted to an electrical item it will more than likely be fitted with a 13 amp fuse regardless of what the wattage is. Mcru rhodium plated uk plug fuses. These are 20mm long to fit inside uk equipment it is important you fit the same fuse rating as per the original fuse.

13a rating only. Hifi tuning gold audio fuses for uk mains plugs. Rhodium plated end caps. All uk moulded plugs bs1363 must have the fuse rating marked on them.

Manufacturers have now standardised plug fuse ratings to be either 3a or 13a. If it s a rewireable type plug and the original fuse size fitted by the manufacturer is not known the recommended method is to use the 700w rule. Automotive glass fuses were made in different lengths to prevent high rated fuses being installed in a circuit intended for a lower rating. For appliances above 700w a 13a fuse should be fitted.
